Hastelloy B3 Flanges Manufacturer, Hastelloy Alloy C276/C22/B2 Threaded Flanges Stockists, Hastelloy C22 Flanges, Hastelloy C276 Flanges, Hastelloy B2 Flanges, Hastelloy Flanges Manufacturer in India
Neelam Forge is a prominent Hastelloy B3 Flanges Manufacturer in India that supplies high-quality Threaded Flanges built from Hastelloy Alloy C276, C22, and B2 for multiple industrial uses. Our manufacturing process includes numerous Hastelloy C22 C276 and B2 flanges, which we supply in dimensions ranging from ½” to 48” to fulfill industry-specific demands. The flanges at Neelam Forge India use premium B3 Hastelloy and C22, C276, and B2 alloys to provide outstanding resistance to corrosion and durability under harsh conditions. We maintain complete adherence to standard protocols both from ISO and international bodies during our role as dependable Hastelloy Flanges stockists.
TABLE OF CONTENTS
Hastelloy C276 Flanges Supplier, Hastelloy B2 Flanges, Hastelloy C22 Flanges, Hastelloy Blind Flange Exporter, C276 Slip On Flange, C276 Flanges, Hastelloy C22 Flanges, Alloy C Flanges, Hastelloy C2000 Flanges Supplier in India
Neelam Forge India is a trusted Hastelloy C276 Flanges Manufacturer and Supplier in India. We also supply Hastelloy B2, C22, and C2000 Flanges for industrial applications across the country. By using advanced technology and high-grade Hastelloy alloys, Neelam Forge India produces durable and corrosion-resistant C276 Slip-On Flanges, Hastelloy Blind Flanges, and Alloy C Flanges. Our flange product range extends from half-inch to forty-eight inches in diameter with flexible length options, and they receive multiple protective coatings, including Hot-Dip Galvanizing, Epox, Anti-Rust Oil, and PTFE Coatings. The company maintains its position as the leading Hastelloy Flanges exporter, which delivers precision-engineered flanges to worldwide industries under strict adherence to international quality standards.
Standard Specification of Hastelloy Industrial Flanges
| Specifications | ASME SB 564/ ASTM B564, |
| Grades | Hastelloy C276 , C22 |
| Size | 1/8″ NB - 48″NB , DN10~DN5000 |
| Dimensions | B 16.47 Series A & B, ANSI/ASME B16.5, BS4504, B16.48, EN-1092, BS 10, DIN, etc. |
| Class | 300#, 150#, 900#, 600#, 2500#, 1500# |
| Standards | ASME Flanges, ASTM, DIN Flanges, ANSI Flanges, BS Flanges, EN Flangesetc. |
| Flange Face Type | Raised Face (RF), Flate Face (FF), Ring Type Joint (RTJ) |
| Flanges Types | Forged Flanges, Expander Flanges, Reducing Flanges, Blind Flanges, Socket Weld Flanges, Orifice Flanges, Flat Flanges, Slip On Flanges, High Hub Blinds Flanges, Lapped Joint Flanges, Threaded Flanges, Nipo Flanges, Long Neck Weld Flanges, Square Flanges, RTJ Flanges etc |
Hastelloy Flanges Grades Available
Check Hastelloy Alloy Flanges suppliers available grades.
Hastelloy Pipe Flanges Weight Chart
| Standard | Diameter | Class | Number of Bolts | Bolt Size | Bolt Circle Diameter | Diameter of Bolt Hole |
|---|---|---|---|---|---|---|
| ANSI B16.5 Flanges | 121 | ANSI 900 Flanges | 4 | 19 | 83 | 22 |
| 95 | ANSI 300 Flanges | 4 | 13 | 67 | 16 | |
| 121 | ANSI 1500 Flanges | 4 | 19 | 83 | 22 | |
| 89 | ANSI 150 Flanges | 4 | 13 | 60 | 16 | |
| 95 | ANSI 600 Flanges | 4 | 13 | 67 | 16 | |
| AS 2129 Flange | 95 | Table F Flanges | 4 | 13 | 67 | 14 |
| 95 | Table D Flanges | 4 | 13 | 67 | 14 | |
| 95 | Table C Flanges | 4 | 13 | 67 | 14 | |
| 114 | Table H Flanges | 4 | 16 | 83 | 17 | |
| 95 | Table E Flanges | 4 | 13 | 67 | 14 | |
| 114 | Table J Flanges | 4 | 16 | 83 | 17 | |
| AS4087 Flanges | 95 | PN14 Flanges | 4 | M12 | 67 | 14 |
| ISO 7005 (DIN) Flange | 90 | PN20 Flanges | 4 | M14 | 60.5 | 16 |
| 95 | PN10 Flanges | 4 | M12 | 65 | 14 | |
| 80 | PN6 Flanges | 4 | M10 | 55 | 11 | |
| 95 | PN16 Flanges | 4 | M12 | 65 | 14 | |
| 95 | PN40 Flanges | 4 | M12 | 65 | 14 | |
| 95 | PN25 Flanges | 4 | M12 | 65 | 14 |
Hastelloy Plate Flange Manufacturer in India at discounted Price, Types of Hastelloy Flanges
Hastelloy Flange Pressure Ratings
| Temperature °C | 300 LBS | 150 LBS | 2500 LBS | 400 LBS | 900 LBS | 600 LBS | 1500 LBS |
|---|---|---|---|---|---|---|---|
| 50 | 51.7 | 19.5 | 430.9 | 68.9 | 155.1 | 103.4 | 258.6 |
| −29~38 | 51.7 | 20.0 | 430.9 | 68.9 | 155.1 | 103.4 | 258.6 |
| 100 | 51.5 | 17.7 | 429.4 | 68.7 | 154.6 | 103.0 | 257.6 |
| 200 | 48.3 | 13.8 | 402.8 | 64.5 | 145.0 | 96.7 | 241.7 |
| 150 | 50.3 | 15.8 | 418.2 | 66.8 | 150.6 | 100.3 | 250.8 |
| 250 | 46.3 | 12.1 | 386.2 | 61.7 | 139.0 | 92.7 | 231.8 |
| 325 | 41.4 | 9.3 | 344.3 | 55.0 | 124.0 | 82.6 | 206.6 |
| 300 | 42.9 | 10.2 | 357.1 | 57.0 | 128.6 | 85.7 | 214.4 |
| 350 | 40.3 | 8.4 | 335.3 | 53.6 | 120.7 | 80.4 | 201.1 |
| 400 | 36.5 | 6.5 | 304.9 | 48.9 | 109.8 | 73.3 | 183.1 |
| 375 | 38.9 | 7.4 | 323.2 | 51.6 | 116.5 | 77.6 | 194.1 |
| 425 | 35.2 | 5.5 | 291.6 | 46.5 | 105.1 | 70.0 | 175.1 |
| 675 | 11.5 | - | 96.0 | 15.4 | 34.6 | 23.0 | 57.6 |
Chemical Composition of Hastelloy Flanges
| Grade | Ni | Mo | Cr | Fe | W | Co | Mn | C | v | P | S | Si |
| Hastelloy C276 | Bal | 15 – 17 | 14.5 – 16.5 | 4 – 7 | 3 – 4.5 | 2.5 max | 1.0 max | 0.01 max | 0.35 max | 0.04 max | 0.03 max | 0.08 max |
Mechanical Properties of Hastelloy Flanges
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.89 g/cm33 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40% |
Hastelloy Flanges Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | GOST | AFNOR | JIS | OR | EN |
| Hastelloy C276 | 2.4819 | N10276 | ХН65МВУ | – | NW 0276 | ЭП760 | NiMo16Cr15W |
Application Of Hastelloy Flanges
Packing Of Hastelloy Flange
The packing is done export-worthy, making sure the client receives our flanges in good condition.
Neelam Forge India is a Manufacturer and Supplier of Hastelloy Flanges supplying in all Ratings up to 2500#.- Neelam Forge India
